MY-WHC700 Windows Hello Face Recognition Binocular USB Camera
Produktbeschreibung
It supports infrared Windows Hello face recognition, it is a popular computer camera in the market.
It adopts UVC protocol, no need driver, plug and play directly, it’s very convenient to use; it supports infrared face recognition, can realize windows hello face unlocking function, and improve the convenience and security of computer use; at the same time, it also supports 1080P video calls with clear picture quality, which can meet users' high-definition video needs.
Direktes Plug-and-Play, einfach zu installieren. Kompatibel mit Windows XP/7/8/10/11 und höheren Systemen. Der Universalclip kann auf allen Desktops, Laptops usw. verwendet werden.
Funktionen und allgemeine Spezifikationen
Grundlegende Spezifikationen der Kamera
|
Items |
Parameters |
|||
|
Name |
USB VR Camera |
USB IR Camera |
||
|
SENSOR |
CMOS |
CMOS |
||
|
Lens Size |
1/2.9" |
1/9" |
||
|
Most effective pixels |
1920*1080 |
640*360 |
||
|
Shutter Type |
Electronic rolling shutter |
Electronic rolling shutter |
||
|
dynamic range |
81dB |
TBD |
||
|
Lens |
Diagonal perspectiveFOV（D） ：89±5° |
Diagonal perspectiveFOV（D） ：80±5° |
||
|
Horizontal view angleFOV（H） ：80±5° |
Horizontal view angleFOV（H） ：69±5° |
|||
|
Vertical viewing angleFOV（V） ：55±5° |
Vertical viewing angleFOV（V） ：42±5° |
|||
|
focusing |
Fixed focus |
Fixed focus |
||
|
Data Format |
MJPG |
YUV |
MJPG |
YUV |
|
Common resolution @ frame rate |
1920*1080@30fps |
1920*1080@5fps |
This camera cannot preview |
|
|
1280*720@30fps |
1280*720@10fps |
|||
|
800*600@30fps |
800*600@30fps |
|||
|
640*480@30fps |
640*480@30fps |
|||
|
320*240@30fps |
320*240@30fps |
|||
|
auto control |
White balance，exposure. |
|||
|
audio |
Stereo/Dual Microphone |
|||
|
Voltage |
USB 5V |
|||
|
working current |
MAX 300mA |
|||
|
USB Connector |
Type-A--USB2.0 |
|||
|
Storage Temperature |
-20℃ to +70℃ |
|||
|
working Temperature |
0℃ to +50℃ |
|||
|
system compatibility |
1、Windows XP（SP2,SP3）、Vista 、7、8、10、11 |
|||
|
2、Mac OS with UVC driver |
||||
|
3、Linux or OS with UVC driver |
||||
Spezifikation der Hauptkomponenten
|
Item |
Key parameter |
Specification |
|
Sensor |
Type |
CMOS |
|
Optical size |
1/2.9 inch |
|
|
Active Array Size |
1920(H) x1080(V) |
|
|
Pixel Size |
2.8μm x 2.8μm |
|
|
MAX Frame Rate |
30fps@Full size |
|
|
Shutter Type |
Electronic Rolling shutter |
|
|
CRA |
12°（linear） |
|
|
Operation temperature range |
-20℃～70℃ |
|
|
Lens |
Type |
MY-7048 |
|
Aperture F/NO |
2.5±5% |
|
|
Viewing angle FOV(Field of View) |
89°(OPT) |
|
|
Construction |
1G4P+IR |
|
|
TV-Distortion |
<-0.9% |
|
|
IR Filter |
650nm |
|
|
EFL |
2.95mm |
|
|
TTL |
15.65±0.2mm |
|
|
Barrel Thread |
M12*P0.5mm |
Produktstrukturdiagramm
