Wide dynamic range AI usb camera modules

Today I would like to introduce our company's wide dynamic range AI usb camera module.

What does wide dynamic camera mean? What is its function?

Users often ask what wide dynamic is and what is the function of wide dynamic of camera?

Wide dynamic is a technology used to allow the camera to see the characteristics of the image under very strong contrast.

When high-brightness areas under strong light sources (sunlight, lamps or reflections, etc.) and relatively low-brightness areas such as shadows and backlights exist in the image at the same time, the image output by the camera will appear white in bright areas due to overexposure, and black in dark areas due to underexposure, which seriously affects the image quality. The camera has limitations in its performance of the brightest area and the darkest area in the same scene. This limitation is what is commonly referred to as "dynamic range".

Therefore, wide dynamic range means that both the brightest and darkest parts of a scene can be seen clearly at the same time. Wide dynamic range is the ratio of the brightest brightness signal value that the image can distinguish to the darkest brightness signal value that it can distinguish. Wide dynamic range cameras can be widely used in highway toll systems, electronic police systems, urban commercial systems, bank automatic doors, ATM machines, and ID card recognition.

Now I recommend our two models wide dynamic range (we also called WDR or HDR) AI usb camera module: MY-USB2M938A (2MP, 105dB) and MY-USB5M208A (5MP, 85dB), pls.see their detailed information as following:

Model: MY-USB2M938A (2MP, 105dB):

1080P resolution HD video driver-free usb camera module with built-in microphone

•1080P Full HD quality (1920*1080)；
• Fixed focus and AF auto focus: Optional
• 89° field of view; distortion-free lens
• Ingebouwde omnidirectionele microfoon;
• No need usb driver, one line direct connection, plug and play directly
Plug and Play direct, geen software nodig, eenvoudig te installeren. Compatibel met Windows XP/7/8/10 en hoger, Linux-besturingssysteem, standaard UVC-protocol. Het ondersteunt OBS, XBox one, Youtube, Facebook, Skype, Xsplit, Mixer. Kan worden gebruikt op alle desktops, laptops, etc.

Model: MY-USB5M208A (5MP, 85dB):
5MP HD video driver-free usb camera module with built-in microphone.

• 5MP Full HD quality(2592*1944)；
• Fixed focus and AF auto focus: Optional
• 102° field of view; distortion-free lens
• Ingebouwde omnidirectionele microfoon;
• No need usb driver, one line direct connection, plug and play directly;
Plug and Play direct, geen software nodig, eenvoudig te installeren. Compatibel met Windows XP/7/8/10 en hoger, Linux-besturingssysteem, standaard UVC-protocol. Het ondersteunt OBS, XBox one, Youtube, Facebook, Skype, Xsplit, Mixer. Kan worden gebruikt op alle desktops, laptops, etc.
We also can customize the wide dynamic range AI usb camera modules and other types camera modules for our customers, if you need camera module, pls.contact with my office mail box: susan@szmyccm.com
